Electric Taug kev iav Nqus Lifter
Txheej txheem cej luam: Advanced Electric Glass Handling Solution
Electric taug kev iav lub tshuab nqus tsev liftermuab kev txhim khu kev qha zoo rau kev ua haujlwm hauv tsev niaj hnub, lub hom phiaj tsim kom muaj kev nyab xeeb txav cov iav loj loj, pob zeb slabs thiab cov ntawv hlau.Electric taug kev iav lub tshuab nqus tsev lifterua haujlwm hnyav-lub luag haujlwm nqa cov haujlwm, nrog kev ua haujlwm muaj peev xwm hla los ntawm300kg txog 800kgnyob rau hauv txawv unit configuration. Ib qho txiaj ntsig tseem ceeb nyob hauv nws qhov ntau yam nqa qhov siab: feem ntau cov qauv ntawm 300kg txog 600kg ncav cuag3500 hli siab tshaj lifting qhov siab, thaum lub luag haujlwm hnyav 800kg variant nce ua haujlwm siab txhua txoj hauv kev5000 hli.
A 360℃phau ntawv tiglub taub hau txhawb kev kho kom zoo, cia cov neeg ua haujlwm txoj haujlwm panes kom raug thaum lub sij hawm glazing haum. Powered los ntawm proven24V DC qhov system- mus ncig teb chaws motors tso zis 1200W los yog 1500W, nqa motors ncov ntawm 2200W - cov khoom tuav ruaj khov nyob rau hauv ib puag ncig kev tsim kho. Qhov zoo tshaj plaws rau high-rise curtain phab ntsa installation nrog rau sab hauv iav muab faib haum, cov koob no sib npaug nqa lub zog, tshuab ruaj khov thiab ua haujlwm yooj yim ntawm qhov chaw.
Tsim los ntawm DAX LIFTER, DXGL-LD series yog tsim los rau kev ua lag luam ua haujlwm ntev ua haujlwm glazing, txo qis kev siv zog thiab txo cov khoom tawg-tawm kev pheej hmoo ntawm qhov chaw.
Ntsiab nta & Cov txiaj ntsig
- ✓ Broad Load Range:Tsib qauv kev xaiv (300, 400, 500, 600, 800) kom phim qhov sib txawv qhov hnyav xav tau.
- ✓ Extended Lifting Qhov siab:Standard 3.5 m lifting qhov siab, nrog hnyav-lub luag hauj lwm unit txhawb 5 m rau high-theem glazing assignments.
- ✓ Kev ua haujlwm siab Flexibility:Taug kev-qab taug kev tsim ntxiv rau tag nrho 360-degree phau ntawv kev sib hloov rau cov khoom sib xyaw ua ke.
- ✓ High-Torque Fais fab Unit:24V DC tsav thiab nqa lub cev muaj zog ua ke nrog cov roj teeb ruaj khov (2 * 12V / 100Ah lossis 120Ah) rau kev ua haujlwm ntev.
- ✓ Txhim khu kev ruaj ntseg tuav:Ntau 300 mm-inch-diameter suction khob (4-8 pieces) tsim kom ruaj khov ntawm tiaj tus, du workpiece nto.
Technical Data
| Qauv | DXGL-LD 300 | DXGL-LD 400 | DXGL-LD 500 | DXGL-LD 600 | DXGL-LD 800 |
|---|---|---|---|---|---|
| Peev xwm (kg) | 300 | 400 | 500 | 600 | 800 |
| Kev tuav kev sib hloov | 360 degree | ||||
| Max nqa qhov siab (mm) | 3500 | 3500 | 3500 | 3500 | 5000 |
| Txoj kev ua haujlwm | taug kev style | ||||
| Roj teeb (V / A) | 2*12/100 | 2*12/120 | |||
| Charger (V / A) | 24/12 | 24/15 | 24/15 | 24/15 | 24/18 |
| taug kev lub cev muaj zog (V / W) | 24/1200 | 24/1200 | 24/1500 | 24/1500 | 24/1500 |
| Nqa lub cev muaj zog (V / W) | 24/2000 | 24/2000 | 24/2200 | 24/2200 | 24/2200 |
| Dav (mm) | 840 | 840 | 840 | 840 | 840 |
| Ntev (mm) | 2560 | 2560 | 2660 | 2660 | 2800 |
| Pem hauv ntej log loj / ntau (mm) | 400*80/1 | 400*80/1 | 400*90/1 | 400*90/1 | 400*90/2 |
| Lub log tsheb loj / qhov ntau (mm) | 250*80 | 250*80 | 300*100 | 300*100 | 300*100 |
| Suction khob loj / qhov ntau (mm) | 300 / 4 | 300 / 4 | 300 / 6 | 300 / 6 | 300 / 8 |
Tej kev siv
Qhov no taug kev iav lub tshuab nqus tsev lifter suits curtain-wall glazing, facade renovation, qhov rais-qhov rooj sib dhos, pob zeb slab installation thiab hlau ntawv tuav. Txoj kev taug kev hauv qab lub chassis cia cov neeg ua haujlwm txav mus los ntawm kev tsim kho hauv pem teb, kev cob qhia thiab chaw ua haujlwm, txo qis kev pheej hmoo ntawm kev nqa cov khoom loj rau cov qauv hnyav.
